CENOS is intuitive FEM software to speed up RF antenna design of any complexity to fit geometric and electromagnetic constraints

Specialized antenna design

simulation software

CENOS Antenna Design is best suited for

Finite element method (FEM) software solves Maxwell’s equations directly with no simplifications or limitations. Therefore, results provided by CENOS are accurate for wide ranges of geometries and antennas, including very complex geometries. For instance, the software is good for high Q, multi-port simulations with arbitrary 3D structures.

Applications

CENOS software is specialized in the simulation of microstrip- and wire-type antennas that include various geometries (fractal, helix, horn, loop, slot, patch, spiral, and others), as well as dipole and monopole antennas.

  • Microstrip antennas

    • Planar antenna

    • Patch antenna

    • Stripline antenna

    • Array

    • Slot antenna

    • Fractal antenna

  • Wire antennas

    • Dipole antenna

    • Monopole antenna

    • Helical antenna

    • Loop antenna

    • Cloverleaf antenna

    • Spiral antenna

    • Yagi-Uda antenna

  • ​​Horn antennas

Unmatched ease-of-use

  • define frequency,
    dissipation

  • substrate, multiple materials

  • boundary conditions

  • feed, multiple ports

     Get radiation pattern:

  • Farfield in 3D, azimuth & elevation plane in polar and cartesian graphs

     Feed properties:

  • Resistance, reactance, impedance, VSWR & others

     Antenna properties:​

  • Directivity, gain, radiation, intensity

  • use CENOS templates

  • import CAD (STEP IGES)

  • build from scratch using FreeCAD editor

Benefits

​CENOS is fast-to-learn and easy-to-use specialized antenna design simulation software for budget-sensitive customers.

CENOS integrates FreeCAD geometry editor to handle geometry of any complexity, provides built-in utilities for handy design of microstrip antennas and arrays, feed networks, wire antennas (including import of NEC files), and arbitrary 3D structures. FreeCAD also allows to import CAD files from external editors like Autodesk Inventor or similar.

CENOS ensures automatic meshing, as well as allows building manual mesh of any detalization level in the specially designed FreeCAD workspace.

For antenna calculation, the current software version utilizes FEM solver to provide accurate simulation for geometries of any complexity, including multi-port, high Q and other cases. Already now, CENOS R&D is pointing to combining the FEM solver with MoM and FDTD methods to provide a unique, optimized (fast and accurate) solution for any particular case.

CENOS provides very powerful visualization capabilities that includes full visualization of fields and graphs powered by Paraview, spreadsheet for data like S11, VSWR, reflection coefficient, etc, and pdf report.

That all makes CENOS a good alternative to well-known general purpose software like HFSS, CST, FEKO and Comsol for budget-sensitive customers looking for specialized antenna design simulation software.
